Technical Parameter |
|
|
Item |
XMC1845 |
|
Chipset |
ASR1803s |
|
Frequency Bands |
XMC1845-EU: FDD LTE: B1/B3/B5/B7/B8/B20/B28 TDD LTE: B38/B40/B41 UMTS: B1/B5/B8 XMC1845-AU： LTE-FDD: B1\B2\B3\B4\B5\B7\B8\B28\B66 LTE-TDD: B40 WCDMA: B1\B2\B4\B5\B8 |
|
Protocol |
4G: 3GPP R9 Cat4 + 3G: 3GPP R7 |
|
Data Rate |
FDD：DL/UL up to 150Mbps/50Mbps, TDD：DL/UL up to 110Mbps/10Mbps； DL/UL up to 21Mbps/5.76Mbps |
|
WiFi Chipset |
AIC8800DW |
|
WiFi Frequency |
2.4GHz, 1~13Channel |
|
Transmit Power |
17±2dBm @ 802.11b 15±2dBm @ 802.11g 13±2dBm @ 802.11n 12±2d2Bm @ 802.11ax |
|
WiFi Antenna |
1*External Antenna |
|
Protocol |
802.11b/g/n/ax |
|
Data Rate |
802.11b:Up to 11 Mbps 802.11g: Up to 54 Mbps 802.11n: Up to 150 Mbps 802.11ax: Up to 286.8 Mbps |
|
Dimension |
112mm×79mm×24mm |
|
Net weight |
105g |
|
Power adapter |
DC 12V,0.5A |
|
Interface |
1FE+USIM+WiFi6 |
|
Indicators |
POWER, WiFi, LTE |
|
Buttons |
Reset |
|
Featured Functions |
TR069/FOTA |
